Model |
BY214x8/20(3)H |
BY214x8/20(4)H |
BY214x8/20(5)H |
Total pressure |
200ton |
200ton |
200ton |
Feeding direction |
Transversal |
Transversal |
Transversal |
Dimension of hot platen |
3000x1300x42mm |
3000x1300x42mm |
3000x1300x42mm |
Number of layers |
3 |
4 |
5 |
Number of platens |
4 |
5 |
6 |
Opening |
300mm |
400mm |
500mm |
Diameter & stroke of Oil cylinder |
Ф120mmx300mm |
Ф120mmx400mm |
Ф120mmx500mm |
Number of cylinders |
8 |
8 |
8 |
Heating medium |
Steam or thermal oil |
Steam or thermal oil |
Steam or thermal oil |
Frame structure |
Welded |
Welded |
Welded |
Working pressure of high pump |
25.2Mpa |
25.2Mpa |
25.2Mpa |
Total power |
7Kw |
7Kw |
7Kw |
Thermal Oil Furnace |
55.5Kw |
55.5Kw |
55.5Kw |
Net Weight (Approx) |
12500Kg |
13600Kg |
14700Kg |
Max working temperature |
120℃ |
120℃ |
120℃ |
