Max Pressure |
120 Tons |
120 Tons |
120 Tons |
Number of Layers |
3 |
4 |
5 |
Hot Plate Size |
1300x2500x42mm |
1300x2500x42mm |
1300x2500x42mm |
Service Opening |
100mm |
100mm |
100mm |
Cylinder Stroke |
300 |
400 |
500 |
Number & Diameter of Cylinders |
6x100mm |
6x100mm |
6x100mm |
Hydraulic Power |
4.5Kw |
4.5Kw |
4.5Kw |
Heating System Power |
37.5KW |
55.5KW |
55.5KW |
Heating Method |
Thermal Oil or Steam |
Thermal Oil or Steam |
Thermal Oil or Steam |
Max High Pressure Pump Power |
26.5Mpa |
26.5Mpa |
26.5Mpa |
Working Temperature |
120 |
120 |
120 |
Voltage |
380V |
380V |
380V |
Overall Dimensions |
4100x1700x2200mm |
4100x1700x2350mm |
4100x1700x2500mm |
Net Weight |
8500Kg |
9500Kg |
10500Kg |
